Supplier

 Motivation

Overview
  • Ideal for active users, this stylish lightweight and adjustable rigid wheelchair reflects the dynamic lifestyle of urban living.
  • Small castor wheels and 24″ (61 cm) rear wheels to help negotiate small spaces.
  • Available in three sizes. Adjustable seat depth, footrest height and angle, backrest height and angle to provide a customized fit.

Intended Users
  • Active adults without postural support needs who regularly use a wheelchair in an urban location.





Price list available upon request.

Contact a sales agent for a free quote.



This product has been approved by the Product Advisory Council.

PRODUCT DETAILS

  • Rigid frame made from aluminum
  • Water-resistant, slung fabric nylon seat upholstery with padding
  • Height adjustment is adjustable in three positions: high, medium, and low
  • Five settings of back support recline
  • Clothes guard included as part of the arm support and is removable for transport
  • High quality contoured molded polyurethane foam pressure relief cushion, water-resistant, and fire-retardant nylon cover
  • Five foot support height settings
  • Foot support can be placed in a forward or backward configuration
  • Calf strap
  • Nine rear wheel positions depending on type of user
  • Quick release caster wheels and rear wheels. Includes backrest folding mechanism for quick disassembly
  • Basic maintenance toolkit, tire repair kit and tire pump included
  • Certifications: ISO 9001
  • Passed ISO 7176
  • For details on the CLASP warranty, click here. All wheelchairs must be registered in order to activate warranty coverage.

SIZES

CLASP Product Number L801MV-S L801MV-M L801MV-L
Seat Width 16″ (41 cm) 18″ (46 cm) 20″ (51 cm)
Seat Depth 18″ (46 cm) as standard, can be adjusted to 16″ (41 cm) and 14.5″ (37 cm)
Back Height From back of seat to top of push handle: 17″ (44 cm); adjustable, three positions: high, medium, and low
Back Angle Adjustable, three positions: upright, middle, and back; total 8º adjustment (middle position is at 90º to seat surface)
Footrest Height Five settings with a total height range of 3″ (7 cm)
Rear Wheel Dimensions Pneumatic, 24’’ x 1″ diameter rear wheels, 36-spoke aluminum rims, 36-spoke hub, two sealed bearings, 1.2cm quick release axles
Rear Wheel Axle Adjustability 9 positions forward/backward over a 95 mm range, measured from 15 mm to 110 mm in front of backrest. Two height optins for axle mount, 35 mm apart.
Caster Dimensions 3″ diameter (7.6 cm)
Overall Width Open 24″, 26″, 29″ (62 cm, 66 cm, 70 cm, 74 cm)
Overall Length 44″ – 47″ (113 cm – 120 cm)
Transportability Quick release caster wheels and rear wheels; includes backrest folding mechanism for quick disassembly
Product Weight 38.4 lb (17.4 kg)
Weight Capacity 250 lb (113 kg)
Packaging One unit per carton
Package Weight 33.1 lb (15 kg) 35.3 lb (16 kg) 37.5 lb (17 kg)
Package Size 27″ x 29″ x 23″ (69 cm x 74 cm x 58 cm)



ACCESSORIES

Home Maintenance Toolkit is included:

  1. Assembly tool kit:
  • 2 Allen keys – “L” shape 5 mm
  • 1 Tool kit (user) bag
  • 2 Wrench multi-size
  • 1 Allen key – “L” shape 4 mm
  • 1 Allen key – “L” shape 6 mm
  1. Tire repair kit
  2. Tire pump

SUPPORT MATERIALS

Product Information Sheet

Download

Fiche d’information sur le produit en français

Télécharger

Página de Información en español

Descargar

Assembly Manual

Download

Health & Mobility Guide

Download

PROVISION

Important:  This wheelchair should be provided by a therapist trained in the Wheelchair Service Training Package – Basic Level.

Have questions about how the ordering process works?

FAQ

Find the most appropriate product for the people you serve.

Product Selection Guides
